Process Automation

Home Process Automation

  • IO Assignment
  • Cabinet GA and wiring drawing (System, Marshalling, Power Distribution Panel, IRP (interposing relay panel), Network, Server, Consoles etc.
  • Wiring / Ferrule & Label Database
  • Loop Drawings
  • Power Consumption & Heat Load Calculation
  • Operator / Aux. Console Design & Room Layout
  • Signal & System Cable Schedule
  • Bill of Material
  • System Architecture
  • AC-DC Distribution

  • Input Reconciliation and verification, input documents like Control Narratives, P&ID Cause & Effect, Logic Diagram, IO Database
  • Logic Development, Loops, Complex Loops, Sequence Logic etc.
  • HMI / Graphics
  • P&ID Marking for Static Development
  • Dynamic Linking with Logic
  • Shape Development –Shapes, Popups, Faceplates etc.
  • System Integration using various Protocol like Profibus, Fieldbus, OPC, Modbus etc.

  • Simulation Testing
  • Integration testing
  • Loop Checking & Logic C
  • Interface Testing (OPC, MODBUS TCP/IP) RS485, RS232, TCP IP/DNP3/RTU/IEC

Vincitore has extensive experience of providing automation solutions for different kinds of processes in Chemical and Pharmaceutical plants, such as Reactor Automation, Batch/Continuous Distillations, Utilities Monitoring and Controls, AHU Controls, Monitoring and Controls of allied equipment like Heat Exchangers, Centrifuges etc.

Vincitore has developed special Functional Blocks and tools for quick and easy configuration of Batch and Continuous processes, controls of endothermic and exothermic reactions involved in processes like Hydrogenation, Nitration, Separation etc.
